full HD and 4K small pixel pitch led wall

Narrow Pixel Pitch Display (NPP Series)

NPP Series:

Small pixel pitch LED display was born to replace LCD video wall, it is more suitable for indoor high-end commercial applications. It provides better colors and visual experience with gap-free.

Product features:

Golden ration 16:9, easily splicing 2K/4K/8K screen.

Ultra light and slim thickness only 40.6mm.

Full Front and rear service.

Simple installation without steel structure.

Modular design with wireless connection.

Wide View Angle.

High heat dissipation efficiency.

No Fan, No noise.

Get Quotes For Free Contact Sales

Product features Video & Specification Specification Contact us Contact Sales

IMD 4-in-1 Package or Full Flip-chip COB Design

With IMD 4in1 package and flip chip COB (optional), the NPP series offers unmatched image quality. A pixel pitch as fine as 0.7mm to 1.875mm, achieving an ultra-high contrast ratio, superior light consistency, durability, making it a top-tier solution for a wide array of professional settings.

High Contrast

The NPP series has an excellent color advantage and high contrast, presenting a more distinctive picture with high contrast, sharper image quality, rich details, vivid colors, and accurate reproduction of image realism.

Strong Against External Impact

New technology like COB, GOB deliver comprehensive, all-around protection against external impacts, ensuring robust defense efficiently.

Vivid Color Transition

Good color processing technology enables a smoother color transition effect between pixels, making the transition to be more layered in vision, presenting the vivid color display effect.

Flexible Splicing

Thanks to the die casting aluminum, the cabinet supports bevel shape, enabling various splicing methods such as right-angle and cube installations, creating more possibility of indoor applications.

7680 High Refresh Rate

NPP series provides 7680 Hz refresh rate, making the display quality more stable when the image is captured by camera.

Application

The NPP series is widely used in control rooms, conference centers, corporate offices. It is also well-suited for museums, galleries, and retail spaces that demand high-end display solutions.

Video & Specification

To ensure that you find the correct solution, please download the specification

Specification Download

Small Pixel Pitch-NPP Series

ITEM	P0.9	P1.2	P1.5	P1.8	P2.5
Pixel Pitch	0.9375mm	1.250mm	1.5625mm	1.875mm	2.5mm
LED Lamp Model	IMD 4in1	SMD1010/4in1	SMD1010/4in1	SMD1010/1212	SMD1515/2020
Brightness (nits)	500nits	800nits	800nits	800-1000nits	800-1000nits
Cabinet Size (W*H)	600x337.5mm	600x337.5mm	600x337.5mm	600x337.5mm	600x337.5mm
Cabinet Weight (kg/cabinet)	5.8kg	5.8kg	5.8kg	5.8kg	5.8kg
Cabinet Resolution (W*H)	640x360	480x270	384x216	320x180	240x135
Density of Pixels (pixels/m2)	1,137,777 pixels	640,000 pixels	409,600 pixels	284,444 pixels	160,000 pixels
Cabinet Material	Die-casting Aluminum
Protection Level	IP30/IP30
Viewing Angle (degree)	160/160
Operating Environment	-20~+50℃ 10%-90% RH
Refresh Rate	1920/3840Hz
Gray Scale	14 bit
Signal Input	DVI, HDMI 1.3/2.0, DP1.2,VGA,SDI etc
Operating Voltage	100-240V AC 50~60Hz
Service Life	100000Hours
Maximum Power (W/m2)	630W/㎡	660W/㎡	640W/㎡	680W/㎡	580W/㎡
Average Power (W/m2)	210W/㎡	231W/㎡	224W/㎡	238W/㎡	203W/㎡
Maintenance Way	Front
